SYSTEM SETUP
11-20 Sysmex SF-3000 Operator's Manual -- Revised September 1995
3.3 Sampler Stop Limits
Use this program to set the upper and lower limits used for stopping auto mode analysis.
A "+" or "-" with a red back-light will appear on the screen to the right of analysis data
that falls outside of the sampler stop limits.
NOTE: "+" and "-" will not appear with data output via DP, GP or HC.
To set sampler stop limits:
(1) Press [Stop Limits] key in the Data Criteria submenu.
The Stop Limits setting screen containing the current setting values and numeric
keys will appear.
(2) Use the [↑] and [↓] keys to select a parameter.
Use the [←] and [→] keys to select the upper or lower limit. The selected limit
will be displayed above the numeric keypads.
STOP
LL
WBC
Mark
Limits
Stop
Limits
Stop
Cond.
Critical
Limits
Return
WBC
UL
ENTER
QUIT
C
78
9
456
123
0
.
2.00
LIMITS
DP:1234567890123
Sysmex
XM HC GP DP SU
Ready
Manual Mode Next No.1234567890123
Sampler
2.00 [X10 / uL]20.00
RBC 2.00 [X10 / uL]
6.00
HBC 6.0 [g / dL]20.0
HCT 20.0 [%]56.0
MCV 75.0 [fL]115.0
MCH 23.0 [pg]40.0
MCHC 29.0 [g / dL]38.0
PLT 3 0 [X10 / uL]500
RDW-SD 25.0 [fL]75.0
RDW-CV 10.0 [%]20.0
PDW 5.0 [fL]30.0
MPV 5.0 [fL]20.0
P-LCR 10.0 [%]70.0
NEUT% 27.0 [%]74.0
LYMPH% 12.0 [%]55.0
MONO% 0 . 0 [ % ]16.0
EO 0.0 [%]8.0
BASO% 0 . 0 [ % ]2.0
NEUT# 0.00 [X10 / uL]7.50
6
3
3
3
↑
←
↓
→
Figure 11-15: Stop Limits Setting Window
NOTE: The settings illustrated on the screen above are the factory settings.
