SYSTEM SETUP
11-18 Sysmex SF-3000 Operator's Manual -- Revised September 1995
3.2 Critical Limits
Use this program to set the upper and lower limits for critical judgment.
The critical limits are used to call attention to life threatening values or to judge data as
unreliable. An exclamation mark (!) with a red back-light will appear to the right of
analysis data that falls outside of the critical limits. However, this exclamation mark will
not appear with data output via DP, GP or HC, only appears on the screen.
NOTE: "Data judged unreliable according to the Critical Limits" means data falls
outside of the normal analysis range due to instrumental abnormality,
patient abnormal values, cell morphology, etc.
To set critical limits:
(1) Press [Critical Limits] key in the Data Criteria submenu.
The Critical Limits setting screen containing the current setting values and numeric
keys will appear.
(2) Use the [↑] and [↓] keys to select a parameter.
Use the [←] and [→] keys to select the upper or lower limit. The current value for
the selected limit will be displayed above the numeric keys.
CRITICAL
LL
WBC
Mark
Limits
Stop
Limits
Stop
Cond.
Critical
Limits
Return
WBC
UL
ENTER
QUIT
C
78
9
456
123
0
•
0.00
LIMITS
DP:1234567890123
Sysmex
XM HC GP DP SU
Ready
Manual Mode Next No.1234567890123
Sampler
0.00 [X10 / uL]99.99
RBC 0.00 [X10 / uL]99.99
HBC 0.0 [g / dL]999.9
HCT 0 . 0 [ % ]999.9
MCV 0.0 [fL]999.9
MCH 0 . 0 [ p g ]999.9
MCHC 0 . 0 [g / dL]999.9
PLT 0 [X10 / uL]9999
RDW-SD 0.0 [fL]999.9
RDW-CV 0.0 [ % ]999.9
PDW 0.0 [fL]999.9
MPV 0.0 [fL]999.9
P-LCR 0.0 [ % ]999.9
NEUT% 0.0 [ % ]999.9
LYMPH% 0.0 [ % ]999.9
MONO% 0 . 0 [ % ]
999.9
EO 0.0 [%]999.9
BASO% 0 . 0 [ % ]999.9
NEUT# 0.00 [X10 / uL]99.99
↑
←
↓
→
3
3
6
3
Figure 11-14: Critical Limits Setting Window
NOTE: The settings illustrated on the screen above are the factory settings.
