INSTALLATION, Preinstallation
Sysmex SF-3000 Operator's Manual -- Revised August 1998 B-5
1. 2 Supplementary Parts Information
When the Sampler Unit and/or Bar Code Reader is not installed for the SF-3000, the
dummy cover and some parts to cover the opening are available. Also when the Manual
CP Unit is installed, some parts are necessary to install the dummy cover.
Order the following items from your Sysmex Sales Representative, if needed.
(1) No optional unit is installed. (SF-3000 system only)
Part No. Description Quantity
951-1311-9 SF-3K Dummy Cover Assy 1
This assy includes Front Panel-C, ID Cover No. 1, Screw Binding M3X6 (SUS), Screw Binding
M4X6 (SUS), Washer Spring M4 (SUS), Rubber Cap No.33 and Wiring Cord No. 1698.
(2) Only the Bar Code Reader is installed.
Part No. Description Quantity
322-3559-4 Front Panel-C 1
348-3812-1 Screw Binding M3X6 (SUS) 6
348-3926-8 Screw Binding M4X6 (SUS) 2
348-9514-3 Washer Spring M4 (SUS) 2
933-4441-1 Wiring Cord No. 1698 1
368-0273-5 Rubber Cap No.33 1
(3) Only the Sampler Unit is installed.
Part No. Description Quantity
322-3600-1 ID Cover No. 1 1
348-3812-1 Screw Binding M3X6 (SUS) 4
348-3926-8 Screw Binding M4X6 (SUS) 2
348-9514-3 Washer Spring M4 (SUS) 2
933-4441-1 Wiring Cord No. 1698 1
(4) Only the Manual CP Unit is installed.
Part No. Description Quantity
322-3600-1 ID Cover No. 1 1
348-3812-1 Screw Binding M3X6 (SUS) 8
348-3926-8 Screw Binding M4X6 (SUS) 1
348-9514-3 Washer Spring M4 (SUS) 1
943-2801-1 Wiring Cord No.1777 1
933-4441-1 Wiring Cord No. 1698 1
(5) When the Manual CP Unit and Bar Code Reader are installed.
Part No. Description Quantity
348-3812-1 Screw Binding M3X6 (SUS) 4
348-3926-8 Screw Binding M4X6 (SUS) 1
348-9514-3 Washer Spring M4 (SUS) 1
943-2801-1 Wiring Cord No.1777 1
933-4441-1 Wiring Cord No. 1698 1
Sysmex SF-3000 Operator's Manual -- Revised March 2001
