Sysmex SF-3000 Operator's Manual -- Revised September 1995 5-67
8.8 Replace the Belt No. 6
If the motor belt of the Reaction Chamber Mixing Motor is cut, the message "Mixing
Motor Speed Error" will appear. Replace the Belt No. 6 as follows.
(1) Turn OFF the power to the Main Unit.
(2) Open the front cover and set the stop bar in position.
WARNING! When working with the front cover open, make sure that the stop bar
is in place to avoid accidental closure.
(3) Disconnect the connector to the Mixing Motor shown in figure below.
Mixing Motor
Pulley
Pulley
Disconnect this
connector.
Figure 5-8-40: Mixing Motor
(4) Remove the Belt No. 6.
