SYSMEX SF-3000 - Appendix C: Technical Information

TECHNICAL INFORMATION
Sysmex SF-3000 Operator's Manual -- Revised September 1995 C-1
APPENDIX C: TECHNICAL INFORMATION
The following technical information has been included for your reference.
1. SERIAL INTERFACE FOR HOST COMPUTER......................... C-2
1.1 Connection ............................................................... C-2
1.2 Input/Output Signals .................................................... C-2
1.3 Communication Format................................................. C-2
1.4 Baud Rate/Character Structure ......................................... C-2
1.5 Signal Level .............................................................. C-3
1.6 Interface Circuit.......................................................... C-3
1.7 Software .................................................................. C-4
2. TEXT FORMAT................................................................ C-8
2.1 Patient Sample Data Format ............................................ C-8
2.2 Quality Control Data Format .......................................... C-12
2.3 Inquiry Data Format.................................................... C-14
2.4 Order Information Data Format ....................................... C-15
3. ID BAR CODE................................................................. C-17
3.1 Applicable Bar Codes .................................................. C-17
3.2 Dimensions of Elements ............................................... C-18
3.3 Requirements on Wide/Narrow Ratio................................ C-18
3.4 Optical Requirements................................................... C-18
3.5 Dimensions of Bar Code Label ....................................... C-20
3.6 Check-Digit.............................................................. C-20
3.7 Applicable Characters .................................................. C-28
3.8 Effective Bar Code Length ............................................ C-28
