SYSMEX SF-3000 User Manual

MAINTENANCE & SUPPLIES, Replacements
Sysmex SF-3000 Operator's Manual -- Revised September 1995 5-63
8.5 Replace the Rubber Plate No. 39 (Auto Sampler Unit)
When the test tubes start to slip from the hand clippers, replace the rubber plate as
follows.
WARNING! The hand clippers should be considered potentially biohazardous.
Do not perform this procedure without proper protective equipment.
Wear rubber gloves when replacing. Wash your hands with an
antiseptic solution after completing the procedure.
(1) Turn OFF the power to the Main Unit.
(2) Pull the CP cover straight up to remove it. See Figure 5-8-35.
(3) Remove the old rubber plate(s) from the hand clipper shown in Figure 5-8-36.
CP Cover
Rubber Plate
Figure 5-8-35: Remove CP Cover Figure 5-8-36: Rubber Plate No. 39
(4) Place a new Rubber Plate No. 39 (found in the supply parts) inside the hand.
(5) Reset the CP cover and turn ON the power.
CAUTION: Take care not to pinch or bend the tubing when replacing the cover.
(6) Record the replacement on the maintenance log.
Sysmex SF-3000 Operator's Manual -- Revised March 2001
