INSTALLATION
B-2 Sysmex SF-3000 Operator's Manual -- Revised September 1995
1. PREINSTALLATION
In addition to verifying the proper power and environmental considerations outlined in
Chapter 1: Introduction, the contents of the boxes shipped to the customer site must be
verified prior to installation.
The SF-3000 system consists of the following units:
• Main Unit
• Pneumatic Unit
• Sampler Unit or Manual CP Unit (Optional)
• Bar Code Reader Unit (Optional)
• Graphic Printer or Line Printer (Optional)
• Data Printer (Optional)
Your Sysmex representative is responsible for unpacking, installing, and the initial set up
of the SF-3000 system. The information in this section is given only for your
completeness.
1.1 Unpacking Check List
Check the contents of each box to verify the following parts have been received:
(1) Main Unit Carton
Part No. Description Quantit
y
117 V 220 V 240 V
943-1912-4 SF-3000 Main Unit 1 - - - - - -
943-1913-8 SF-3000 Main Unit - - - 1 - - -
943-1914-1 SF-3000 Main Unit - - - - - - 1
943-2271-0 Air Drier No. 3 Assembly 1 1 1
462-2121-3 Awl 1 1 1
342-2626-4 Belt No.6 1 1 1
424-3733-7 Bottle Stand No.2-1 (Cream) 1 1 1
844-0122-8 Cubitainer Spout Kit CS-61 (C2) 2 2 2
943-1781-1 Cubitainer Spout Kit No. 1 (20 L) 1 1 1
462-2423-7 Cutting Pliers B-150 MM 1 1 1
362-8350-1 Decoration Seal No. 1 1 1 1
883-0192-3 Dispenser Kit No.1 (for 500 mL bottle) 2 2 2
363-1371-1 Fixing Metal No. 81 - - - - - - 1
266-5011-3 Fuse 250V4A ST4-4A-N1 (N.Amer) 2 - - - - - -
266-5106-0 Fuse 250V6.3A ST4-6.3A-N1 (N.A.) 1 - - - - - -
266-5108-7 Fuse 250V8A ST4-8A-N1 (N.Amer) 2 - - - - - -
266-5292-6 Fuse 250V2A No.19195 (Europe) - - - 2 2
266-5293-0 Fuse 250V3.15A No. 19195 (Europe) - - - 1 1
266-5297-4 Fuse 250V4A No.19195 (Europe) - - - 2 2
(To Be Continued)
