SYSMEX SF-3000 User Manual

INSTALLATION
B-6 Sysmex SF-3000 Operator's Manual -- Revised September 1995
2. LAYOUT AND WORK SPACE
Leave a space of at least 50 cm above and behind the instrument and at both sides. This
is for convenience when servicing the instrument, and to allow for dissipation of heat
from the instrument. The power outlets and drainage channel should be near the
instrument. The power cords are 1.8 m long and the drain tube is 10 m long in the
maximum. The Pneumatic Unit, reagents and printers should also be installed in
convenient location.
730
600
580
195
334
395
Figure B-1: Dimensions of System
