FUNCTIONAL DESCRIPTIONS, Main Unit

Sysmex SF-3000 Operator's Manual -- Revised September 1995 10-23

(4) Power Connector

Supplies power via power cord provided.

(5) Fuse 2

This is an over-current protection fuse for the Pneumatic power outlet. Replace

with provided time lag type fuse. The rating will be different depending on the

instrument specification.

Specification Part No. Description Fuse

Type

117 VAC 266-5106-0 Fuse 250V6.3A ST4-6.3A-N1 Time Lag

220/240 VAC 266-5293-0 Fuse 250V3.15A No. 19195 Time Lag

(6) Pneumatic Power Outlet

Supplies power to the Pneumatic Unit. When the Pneumatic Unit is not operated

for preset time period, the Main Unit automatically powers off the Pneumatic Unit.
