FUNCTIONAL DESCRIPTIONS, Main Unit
Sysmex SF-3000 Operator's Manual -- Revised September 1995 10-31
(6) PCB No. 9243
This is a mother board.
(7) CPU Unit No. 12
This CPU board and extended memory board control the entire SF-3000 electric
system.
(8) I/O Board No. 5 Assy
This I/O board has following interfaces and functions; a keyboard interface, printer
interface, serial I/O interface, AGDC (Advanced Graphic Display Controller),
SCSI (Small Computer System Interface), DMA (Direct Memory Access), FDC
(Floppy Disk Controller), and Bus Interface.
(9) PCB No. 1232
This board includes a WBC scattergram analysis function, stepper motor control,
and serial interface I/O to and from the Sampler and ID reader.
(10) PCB No. 1223
This is an RBC PDA board.
(11) SF-3000 Power Supply Unit
Supplies required voltages and current to each unit.
NOTE: Parts information for ordering is given below.
Part Code No. Part Description
<PCB No. 2119> 943-2391-0 PCB No. 2119
<LCD Unit> 228-3700-6 LCD KCL6448HSTT-X14
228-9350-2 Inverter KCL-T1
263-9175-0 Touch Panel H94-51
943-2441-9 PCB No. 9245
<PCB No. 1234> 943-2361-8 PCB No. 1234
<HD Drive> 241-9412-6 Hard Disk Unit M2681SA
<FD Drive> 241-9325-9 Floppy Disk Drive JU-256A025P
<PCB No. 9243> 943-2431-1 PCB No. 9243
< CPU Unit > 943-2411-7 PCB No. 6358
943-2421-4 PCB No. 7013 (C-1/4MB)
943-2461-3 ROM 2SF31 Assy
<I/O Board> 943-2321-9 PCB No. 122901 with ROM 3SF31
943-2471-1 ROM 3SF31 Assy
943-2331-6 PCB No. 1230
<PCB No. 1232> 943-2341-3 PCB No. 1232
<PCB No. 1223> 933-3952-5 PCB No. 1223 with ROM (C2/SF)
