Command groups

Table 2-21: Bus commands (cont.)

Command Description

BUS:B<x>:I2C:CLOCk:SOUrce Sets or queries the I2C clock (SCLK) source for the speciﬁed bus.

BUS:B<x>:I2C:CLOCk:THReshold Sets or queries the I2C Clock (SCLK) source threshold for the speciﬁed bus.

BUS:B<x>:I2C:D ATa:SOUrc e Sets or queries the I2C data (SDA) source for the speciﬁed bus.

BUS:B<x>:I2C:D ATa:THR eshold Sets or queries the I2C Data (SDA) source threshold for the speciﬁed bus.

BUS:B<x>:I2C:RWINADDR Determines whether decoded I2C slave addresses are pure seven-bit values,

or have the R/W* combined with them.

BUS:B<x>:LABel:COLor Sets or queries the color of the speciﬁed bus label.

BUS:B<x>:LABel:FONT:BOLD Sets or queries the bold s tate of the speciﬁed bus label.

BUS:B<x>:LABel:FONT:ITALic Sets or queries the italic state of the speciﬁed bus label.

BUS:B<x>:LABel:FONT:SIZE Sets or queries the font size of the speciﬁed bus label.

BUS:B<x>:LABel:FONT:TYPE Sets or queries the font type of the speciﬁed bus label, such as Arial or Times

New Roman.

BUS:B<x>:LABel:FONT:UNDERline Sets or queries the underline state of the speciﬁed bus label.

BUS:B<x>:LABel:name Sets or queries the waveform label for the speciﬁed bus.

BUS:B<x>:LABel:XPOS Sets or queries the x-position of the speciﬁed bus' label.

BUS:B<x>:LABel:YPOS Sets or queries the y-position of the speciﬁed bus' label.

BUS:B<x>:LIN:BITRate Sets or queries the LIN bus bit rate.

BUS:B<x>:LIN:ID FORmat Sets or queries LIN bus id format.

BUS:B<x>:LIN:PO Larity Sets or queries the LIN bus polarity.

BUS:B<x>:LIN:SAMPLEpoint Speciﬁes the point to sample during each bit period, as a percent, for the

speciﬁed LIN bus.

BUS:B<x>:LIN:SOUrce Sets or queries sets the LIN bus source.

BUS:B<x>:LIN:SOUrce:THReshold Sets or queries the LIN source threshold for the speciﬁed bus.

BUS:B<x>:LIN:STANDard Sets or queries the LIN bus standard.

BUS:B<x>:LIN:BITRate:CUSTom Sets or queries LIN custom bit rate for the speciﬁed bus.

BUS:B<x>:MIL1553B:SOUrce Sets or queries the source for the speciﬁed MIL-STD-1553 bus.

BUS:B<x>:MIL1553B:THRESHold Sets or queries the MIL-STD-1553 upper threshold for the speciﬁed bus.

BUS:B<x>:MIL1553B:LOWTHRESHold Sets or queries the MIL-STD-1553 lower threshold for the speciﬁed bus.

BUS:B<x>:MIL1553B:POLarity Sets or queries the source polarity for the speciﬁed MIL-STD-1553 bus.

BUS:B<x>:MIL1553B:RESPonsetime:MINimum Sets or queries the minimum response time to a valid command issued for the

speciﬁed MIL-STD-1553 bus.

BUS:B<x>:MIL1553B:RESPonsetime:MAXimum Sets or queries the maximum response time to a valid command issued for the

speciﬁed MIL-STD-1553 bus.

BUS:B<x>:PARallel:ALLTHResholds Sets or queries the threshold for all sources for the parallel bus.

BUS:B<x>:PARallel:ALLTHResholds:APPly Sets all of the data s ource thresholds to the value of the allMRefs parameter for

the parallel bus.

BUS:B<x>:PARallel:BIT<n>SOUrce Sets or queries the speciﬁed bit source for speciﬁed parallel bus.

BUS:B<x>:PARallel:BIT<n>SOUrce:THReshold Sets or queries the speciﬁed bit source threshold for the speciﬁed parallel bus.

2-16 MSO54, MSO56, MSO58, MSO58LP Programmer
