Command groups

Table 2-21: Bus commands (cont.)

Command Description

BUS:B<x>:PARallel:CLOCk:EDGE Determines which edges of its clock signal cause a clocked parallel bus to

sample new states.

BUS:B<x>:PARallel:CLOCk:ISCLOCK ED Determines whether the bus operates in a clocked or asynchronous fashion.

BUS:B<x>:PARallel:CLOCkSOUrce Sets or queries the Parallel clock source for the speciﬁed bus.

BUS:B<x>:PARallel:CLOCKSOUrce:THReshold Sets or queries the bit source threshold for the parallel bus.

BUS:B<x>:RS232C:BITRate Sets or queries the RS-232 bit rate for the speciﬁed bus.

BUS:B<x>:RS232C:BITRate:CUSTom Sets or queries the RS232 custom bit rate for the speciﬁed bus.

BUS:B<x>:RS232C:DATABits Sets or queries the number of RS-232 data bits for the speciﬁed bus.

BUS:B<x>:RS232C:DELIMiter Sets or queries the RS-232 delimiting value for a packet on the speciﬁed bus.

BUS:B<x>:RS232C:DISplaymode Sets or queries the display mode for the speciﬁed bus.

BUS:B<x>:RS232C:PARity Sets or queries the RS-232 parity for the speciﬁed bus.

BUS:B<x>:RS232C:POLarity Sets or queries the RS-232 polarity for the speciﬁed bus.

BUS:B<x>:RS232C:SOUrce Sets or queries the RS-232 polarity for the speciﬁed bus.

BUS:B<x>:RS232C:SOUrce:THReshold Sets or queries the RS232 source threshold for the s peciﬁed bus.

BUS:B<x>:SPI:BITOrder Sets or queries the shift direction used to de-serialize data for the SPI mode of

the bus.

BUS:B<x>:SPI:CLOCk:POLarity Sets or queries the SPI clock (SCLK) polarity for the s peciﬁed bus.

BUS:B<x>:SPI:CLOCk:SOUrce Sets or queries the SPI clock (SCLK) source for the speciﬁed bus.

BUS:B<x>:SPI:CLOCk:THReshold Sets or queries the SPI Clock (SCLK) source threshold for the speciﬁed bus.

BUS:B<x>:SPI:DATa:POLarity Sets or queries the SPI data (DATA) polarity for the speciﬁed bus.

BUS:B<x>:SPI:DATa:SIZe Sets or queries the number of bits per word for the speciﬁed bus.

BUS:B<x>:SPI:DATa:SOUrce Sets or queries the SP I data (DATA) source for the speciﬁed bus.

BUS:B<x>:SPI:DATa:THReshold Sets or queries the SPI Data (SDA) source threshold for the speciﬁed bus.

BUS:B<x>:SPI:FRAMING Sets or queries the S PI bus framing.

BUS:B<x>:SPI:IDLETime Sets or queries the SPI bus idle time.

BUS:B<x>:SPI:SELect:POLarity Sets or queries the SPI Slave Select (SS) polarity for the speciﬁed bus.

BUS:B<x>:SPI:SELect:SOUrce Sets or queries the SPI Slave Select (SS) source for the speciﬁed bus.

BUS:B<x>:SPI:SELect:THReshold Sets or queries the SPI Select (SS) source threshold for the speciﬁed bus.

BUS:B<x>:TYPe Sets or queries the bus type speciﬁed.

BUS:B<x>:USB:BITRate Sets or queries the USB bit rate for the speciﬁ ed bus.

BUS:B<x>:USB:SOUrce Sets or queries the USB D ata Source for the speciﬁed bus.

BUS:B<x>:USB:SOUrce:DMINus Sets or queries the USB Data S ource for D- input for the speciﬁed bus.

BUS:B<x>:USB:SOUrce:DPLUs Sets or queries the USB Data Source for D+ input for the speciﬁed bus.

BUS:B<x>:USB:DATAMINUSTHRESHold Sets or queries the USB DATA M inus source threshold for the s peciﬁed bus.

BUS:B<x>:USB:DATAPLUSTHRESHold Sets or queries the USB DATA Plus source threshold for the speciﬁed bus.

BUS:B<x>:USB:LOWTHRESHold Sets or queries the USB DATA s ource Low threshold for the speciﬁed bus.

BUS:B<x>:USB:SIGNALTYpe Sets or queries the USB signal type for the speciﬁed bus.

MSO54, MSO56, MSO58, MSO58LP Programmer 2-17
