Tektronix MSO54 Programmer's Manual

Command groups
Table 2-31: Measurement commands (cont.)
Command
Description
MEASUrement:MEAS<x>:JITTERSummary:
DJDD
This command sets or queries whether DJ-dd is included in the j itter summary for
the measurement.
MEASUrement:MEAS<x>:JITTERSummary:
EYEWIDTHBER
This command sets or queries whether EyeWidth@BER is included in the jitter
summary for the measurement.
MEASUrement:MEAS<x>:JITTERSummary:
NPJ
This command sets or queries whether NPJ is included in the jitter summary for the
measurement.
MEASUrement:MEAS<x>:JITTERSummary:PJ This command sets or queries whether PJ is included in the jitter summary for the
measurement.
MEASUrement:MEAS<x>:JITTERSummary:
RJDD
This command sets or queries whether RJ-dd is included in the j itter summary for
the measurement.
MEASUrement:MEAS<x>:JITTERSummary:TIE This command sets or queries whether TIE is included in the jitter summary for the
measurement.
MEASUrement:MEAS<x>:JITTERSummary:
TJBER
This command sets or queries whether TJ@BER is included in the jitter summary for
the measurement.
MEASUrement:MEAS<x>:LABel This command sets or queries the label for the measurement.
MEASUrement:MEAS<x>:LOWREFVoltage This command sets or queries the low reference voltage value for the 'time outside
level' measurement.
MEASUrement:MEAS<x>:MEASRange:
GLOBal
This command sets or queries the range settings global flag for the measurement.
MEASUrement:MEAS<x>:MEASRange:MAX This command sets or queries the range maximum value for the measurement.
MEASUrement:MEAS<x>:MEASRange:MIN This command sets or queries the range minimum value for the measurement.
MEASUrement:MEAS<x>:MEASRange:STATE This command sets or queries the range state for the measurement.
MEASUrement:MEAS<x>:
PATTERN DE TEC TIO N
This command sets or queries the pattern detection type for the measurement.
MEASUrement:MEAS<x>:PATTERNLE Ngth This command sets or queries the pattern length for the measurement.
MEASUrement:MEAS<x>:PATTERNTYPe This command sets or queries the pattern type for the measurement.
MEASUrement:MEAS<x>:PERFREQ:EDGE This command sets or queries the edge type of a Period/Frequency measurement.
MEASUrement:MEAS<x>:POLarity This command sets or queries the polarity for the measurement when the
measurement type is burst width.
MEASUrement:MEAS<x>:POPUlation:GLOBal This command sets or queries the population settings global flag.
MEASUrement:MEAS<x>:POPUlation:LIMIT:
STATE
This command sets or queries the population limit state for the m easurement.
MEASUrement:MEAS<x>:POPUlation:LIMIT:
VALue
This command sets or queries the population limit value for the measurement.
MEASUrement:MEAS<x>:REFLevels:
ABSolute:FALLHigh
This command sets or queries the value used as the high reference level of the falling
edge when the measurement's ref level method is set to absolute.
MSO54, MSO56, MSO58, MSO58LP Programmer 2-47
