Tektronix MSO54 Programmer's Manual

Command groups
Table 2-31: Measurement commands (cont.)
Command
Description
MEASUrement:MEAS<x>:REFLevels<x>:
ABSolute:FALLLow
This command sets or queries the value used as the low reference level of the falling
edge when the measurement's ref level method is set to absolute.
MEASUrement:MEAS<x>:REFLevels<x>:
ABSolute:FALLMid
This command sets or queries the value used as the mid reference level of the falling
edge when the measurement's ref level method is set to absolute.
MEASUrement:MEAS<x>:REFLevels<x>:
ABSolute:HYSTeresis
This command sets or queries the value of the hysteresis of the reference level when
the measurement's ref level method is set to absolute.
MEASUrement:MEAS<x>:REFLevels<x>:
ABSolute:RISEHigh
This command sets or queries the value used as the high reference level of the rising
edge when the measurement's ref level method is set to absolute.
MEASUrement:MEAS<x>:REFLevels<x>:
ABSolute:RISELow
This command sets or queries the value used as the low reference level of the rising
edge when the measurement's ref level method is set to absolute.
MEASUrement:MEAS<x>:REFLevels<x>:
ABSolute:RISEMid
This command sets or queries the value used as the mid reference level of the rising
edge when the measurement's ref level method is set to absolute.
MEASUrement:MEAS<x>:REFLevels<x>:
ABSolute:TYPE
This command sets or queries the reference level type for the measurement.
MEASUrement:MEAS<x>:REFLevels<x>:
BASETop
This command sets or queries the method used to calculate the TOP and BASE used
to calculate reference levels for the measurement.
MEASUrement:MEAS<x>:REFLevels<x>:
METHod
This command sets or queries the method used to calculate reference levels for
the measurement.
MEASUrement:MEAS<x>:REFLevels<x>:
PERCent:FALLHigh
This command sets or queries the percentage (where 100% is equal to TOP and 0%
is equal to BASE) used to calculate the high reference level of the falling edge when
the m easurement's ref level method is set to percent.
MEASUrement:MEAS<x>:REFLevels<x>:
PERCent:FALLLow
This command sets or queries the percentage (where 100% is equal to TOP and 0%
is equal to BASE) used to calculate the low reference level of the falling edge when
the m easurement's ref level method is set to percent.
MEASUrement:MEAS<x>:REFLevels<x>:
PERCent:FALLMid
This command sets or queries the percentage (where 100% is equal to TOP and 0%
is equal to BASE) used to calculate the mid reference level of the falling edge when
the m easurement's ref level method is set to percent.
MEASUrement:MEAS<x>:REFLevels<x>:
PERCent:HYSTeresis
This command sets or queries the percentage (where 100% is equal to MA X and 0%
is equal to MIN) used to calculate the hysteresis of the reference level when the
measurement's ref level method is set to percent.
MEASUrement:MEAS<x>:REFLevels<x>:
PERCent:RISEHigh
This command sets or queries the percentage (where 100% is equal to TOP and 0%
is equal to BASE) used to calculate the high reference level of the r ising edge when
the m easurement's ref level method is set to percent.
MEASUrement:MEAS<x>:REFLevels<x>:
PERCent:RISELow
This command sets or queries the percentage (where 100% is equal to TOP and 0%
is equal to BASE) used to calculate the low reference level of the rising edge when
the m easurement's ref level method is set to percent.
MEASUrement:MEAS<x>:REFLevels<x>:
PERCent:RISEMid
This command sets or queries the percentage (where 100% is equal to TOP and 0%
is equal to BASE) used to calculate the mid reference level of the rising edge when
the m easurement's ref level method is set to percent.
2-48 MSO54, MSO56, MSO58, MSO58LP Programmer
