Benelli TNT125 Service Manual

Replacing and filling rear brake fluid
●Disassemble:
Reservoir cap [A], reservoir gasket.
●Loosen the bleed screw of slave pump of rear brake
[B], and vacuumize from the bleed screw using a
vacuum pump to pump the brake fluid completely.
●Add new brake fluid to master cylinder reservoir,
keep the brake fluid in the reservoir not less than 1/3 of
its volume, and pull the brake lever for several times
quickly, and lock the bleed screw of slave cylinder [B].
Note
○Operate the brake rod and feel. If you feel that it is
softer than before, please repeat the above actions to
refill.
Remark
○
Check the brake fluid level in the reservoir
frequently and add new brake fluid as needed. If the
brake fluid in
the reservoir runs out during the
replacement of the brake fluid, the air in the brake
pipe must be exhausted.
○
Rear brake: Please repeat the above steps to
remove the calipers.
- 104 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
