TASK 72-00-00-206-117-G00
5. Radiographic Engine Inspection
A. Location Zones
Zone Area
410 Left Powerplant
415 Left Powerplant Fan Reverser - Left
417 Left Powerplant Core Cowl - Left
420 Right Powerplant
425 Right Powerplant Fan Reverser - Left
427 Right Powerplant Core Cowl - Left
B. Procedure
SUBTASK 72-00-00-866-167-G00
WARNING
YOU MUST OBEY THE NECESSARY SAFETY PRECAUTIONS AND ALL
APPLICABLE REGULATORY AGENCY REGULATIONS. THE RADIOGRAPHIC
INSPECTION USES RADIOACTIVE MATERIAL. IF YOU ARE NEAR THE
RADIOACTIVE MATERIAL FOR TOO MUCH TIME, INJURIES OR DEATH CAN
OCCUR.
(1) The gamma ray radiographic inspection procedure can be used to find mechanical condition of
an internal engine component without engine disassembly.
SUBTASK 72-00-00-266-168-G00
(2) Refer to the G.E. CF6-80A Turbofan Engine, Nondestructive Test Manual, Part 3. for Gamma
Ray radiographic inspection procedures.
END OF TASK
TASK 72-00-00-206-118-G00
6. Ultrasonic Inspection
A. General
(1) The ultrasonic inspection is used to find cracks in the dovetails of the 6th and 7th-stage
compressor blades without engine dissassembly.
(2) Refer to the G.E., CF6-80A Turbofan Engine, Nondestructive Test Manual, Part 4 Ultrasonic
Inspection, for the ultrasonic inspection procedures.
END OF TASK
TASK 72-00-00-206-156-G00
7. Inspection of Engines Involved in Accidents or Incidents
A. General
(1) If an engine has had an accident, incident or other unusual exposure, you must follow special
inspection and parts disposition.
An engine exposed to unusual conditions could have to follow special inspection and parts
dispositions that are more than the regular operation limits. Some of the unusual incidents are:
(a) Shock loading, collision, crash damage, separation from the aircraft, handling or
transportation accident.
(b) Structural overstress to the engine structure that holds the weight of the aircraft during a
failure or separation of the landing gear.
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-00-00
NoC
Page 683
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
