Boeing 767 - Task 72-31-02-404-008-G00 - Install the Fan Rotor Blades

TASK 72-31-02-404-008-G00
3. Install the Fan Rotor Blades
(Figure 401)
A. General
(1) This task gives instructions on how to install the fan rotor blades. If you will install repaired
blades, do the steps to install and balance repaired blades.
B. Parts
AMM
NOMENCLATURE
AIPC
FIG ITEM SUBJECT FIG ITEM
401 [1] Bolt 72-31-01 03 25
[2] Balance Weight 20
[3] Retainer 13
[4] Spacer 12
[5] Key 30
[6] 1st-Stage Fan Blade 15
C. References
Reference Title
71-00-00 P/B 501 POWER PLANT - ADJUSTMENT/TEST
72-31-00 P/B 501 FAN AND LOW PRESSURE COMPRESSOR SECTION -
ADJUSTMENT/TEST
72-31-01 P/B 401 FAN ROTOR SPINNER - REMOVAL/INSTALLATION
72-33-04 P/B 801 FAN FRAME - REPAIRS
D. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
COM-4836 Gage - Hole
767-200
Part #: 829B Supplier: 64204
COM-6392 Gage - Hole
767-200
Part #: 829A Supplier: 64204
SPL-6387 Tool - Preload, Fan Blade
767-200
Part #: 2C8073G05 Supplier: 06083
SPL-12873 Fixture - Runout, Fan Rotor Assembled Engine
767-200
Part #: 2C6951G01 Supplier: 06083
STD-123
Brush - Soft Bristle
STD-595
Micrometer
STD-6378
Protective Mat - Rubber, Manufacturers Association, Grade SC43,
neoprene sponge, 1 inch thick, approximately 3 x 4 feet with warning
streamer attached
STD-6556
Gun - Caulking
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-02
NoC
Page 404
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
