Boeing 767 - Task 72-31-02-308-015-G00 - Repair the Fan Case Shroud; Subtask 72-31-02-018-016-G00; Subtask 72-31-02-218-017-G00; Subtask 72-31-02-328-018-G00

TASK 72-31-02-308-015-G00
4. Repair the Fan Case Shroud
A. References
Reference Title
71-00-00 P/B 201 POWER PLANT (OPERATING PROCEDURES) -
MAINTENANCE PRACTICES
72-31-02 P/B 401 FAN ROTOR BLADES - REMOVAL/INSTALLATION
72-31-02 P/B 601 FAN ROTOR BLADES - INSPECTION/CHECK
72-33-04 P/B 601 FAN FRAME - INSPECTION/CHECK
B. Location Zones
Zone Area
412 Left Powerplant Nose Cowl
422 Right Powerplant Nose Cowl
C. Procedure
SUBTASK 72-31-02-018-016-G00
(1) Do the steps that follow to prepare for the repair:
(a) Remove the seized fan blade or blades (PAGEBLOCK 72-31-02/401).
(b) Examine the blade or blades (PAGEBLOCK 72-31-02/601).
1) Do the steps to repair the blade (or blades) if it is necessary.
SUBTASK 72-31-02-218-017-G00
(2) Examine the abradable shroud material on the forward fan case (PAGEBLOCK 72-33-04/601).
SUBTASK 72-31-02-328-018-G00
(3) Repair the lower half of the fan case shroud (between the 3 and 9 o'clock positions) as follows:
(a) Blend the damage (the distortion looks like steps) in the area of the blade trailing edge.
1) Use a fine file, an abrasive cloth, or an abrasive stone to do the blend repair.
2) Lightly blend the damage in a forward to aft direction.
3) Blend at least 0.60 inch (15.2 mm) and not more than 0.75 inch (19.1 mm) from the
edge of the damage.
SUBTASK 72-31-02-418-019-G00
(4) Do the steps that follow to put the engine in its usual condition:
(a) Install the fan blade (or blades) that were removed (PAGEBLOCK 72-31-02/401).
1) Make sure the fan blades are put back in the initial positions.
SUBTASK 72-31-02-718-020-G00
(5) Do the test of the fan rotor blades that is shown in the Power-Plant Test-Reference Table
(PAGEBLOCK 71-00-00/201).
END OF TASK
