(b) Tighten the plugs to the torque values shown in Table 601.
1) Install lockwire.
(c) Install the ECS duct (Figure 601).
SUBTASK 72-00-00-416-148-G00
(12) If it is necessary, do the steps that follow to put the airplane to its usual condition:
NOTE: Do not do these steps if you will continue the inspection at this time.
(a) Remove the equipment that you used to turn the N2 rotor (PAGEBLOCK 72-00-00/201).
WARNING
OBEY THE INSTRUCTIONS IN THE PROCEDURE TO CLOSE THE
THRUST REVERSERS. IF YOU DO NOT OBEY THE INSTRUCTIONS,
INJURIES TO PERSONS AND DAMAGE TO EQUIPMENT CAN OCCUR.
(b) Close the thrust reversers (PAGEBLOCK 78-31-00/201).
(c) Close the core cowl panels (PAGEBLOCK 71-11-06/201).
(d) Do the activation procedure for the thrust reverser (PAGEBLOCK 78-31-00/201).
(e) Close the fan cowl panels (PAGEBLOCK 71-11-04/201).
H. Borescope Inspection of the High Pressure Turbine
SUBTASK 72-00-00-986-026-G00
(1) Do the steps to manually (or pneumatically) turn the N2 rotor at the accessory gearbox
(PAGEBLOCK 72-00-00/201).
NOTE: It is recommended that you turn the N2 rotor, then stop to do the inspection. Then, turn
the N2 rotor, and stop again to do the next inspection.
SUBTASK 72-00-00-016-027-G00
(2) If it is necessary, do the steps that follow to prepare for the borescope inspection:
WARNING
DO THE THRUST REVERSER DEACTIVATION PROCEDURE TO
PREVENT THE OPERATION OF THE THRUST REVERSER. THE
ACCIDENTAL OPERATION OF THE THRUST REVERSER CAN CAUSE
INJURIES TO PERSONS OR DAMAGE TO EQUIPMENT.
(a) Do this procedure: Thrust Reverser Deactivation for Ground Maintenance
(PAGEBLOCK 78-31-00/201).
(b) Open the fan cowl panels (PAGEBLOCK 71-11-04/201).
(c) Open the core cowl panels (PAGEBLOCK 71-11-06/201).
SUBTASK 72-00-00-016-029-G00
CAUTION
PUT A LABEL ON THE BORESCOPE PLUGS. ENGINE DAMAGE CAN OCCUR
IF THE BORESCOPE PLUGS ARE NOT INSTALLED IN THE CORRECT
LOCATION.
(3) If it is necessary, do the steps that follow to remove borescope plugs B2-1 through B2-6:
(a) Remove the borescope plugs B2-1 through B2-5 to examine the 1st-stage nozzle vanes
(Figure 601).
1) Put labels on the borescope plugs that you removed.
(b) Remove the ECS duct to get access to borescope plug B2-6 (Figure 601).
(c) Remove the borescope plug B2-6.
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-00-00
NoC
Page 611
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
