FAN (AND LOW PRESSURE COMPRESSOR) SECTION - MAINTENANCE PRACTICES
1. General
A. This procedure gives instructions for the tasks that follow:
(1) Remove the No. 1 Bearing Manifold
(2) Install the No. 1 Bearing Manifold
(3) Examine the No. 1 Bearing Manifold
(4) Examine and Clean the Fan Midshaft
(5) Examine the First Stage Disk
TASK 72-31-00-002-001-G00
2. Remove the No. 1 Bearing Manifold
A. References
Reference Title
72-31-01 P/B 401 FAN ROTOR SPINNER - REMOVAL/INSTALLATION
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-4783 Puller - Manifold, No. 1 Bearing
767-200
Part #: 2C14871G01 Supplier: 06083
Opt Part #: 2C6823G01 Supplier: 06083
C. Location Zones
Zone Area
412 Left Powerplant Nose Cowl
422 Right Powerplant Nose Cowl
D. Procedure
(Figure 201)
SUBTASK 72-31-00-012-002-G00
(1) Remove the fan rotor spinner (PAGEBLOCK 72-31-01/401).
NOTE: Do not loosen the balance weight screws in the spinner cone.
SUBTASK 72-31-00-032-003-G00
(2) Remove the bolts that hold the No. 1 bearing manifold.
SUBTASK 72-31-00-022-004-G00
(3) Use the puller, SPL-4783 to remove the No. 1 bearing manifold.
(a) Discard the packings.
END OF TASK
