Boeing 767 - Task 72-31-00-202-019-G00 - Examine the First Stage Disk; Subtask 72-31-00-212-020-G00

TASK 72-31-00-202-019-G00
6. Examine the First Stage Disk
A. Location Zones
Zone Area
412 Left Powerplant Nose Cowl
422 Right Powerplant Nose Cowl
B. Procedure
SUBTASK 72-31-00-212-020-G00
(1) Visually examine the first stage disk for the conditions that follow:
Condition Maximum Serviceable Limits
Cracks Not Permitted.
Nicks and scratches Permitted, if they are less than 0.010 inch (0.25 mm) in
depth (after the high metal is removed).
Nicks and scratches on the dovetail slots, disk bore, bore
faces, and the aft side of web
Permitted if they are less than 0.003 inch (0.8 mm) in depth.
Wear of the Cu-Ni-Indium layer on the dovetail pressure
faces
75% of the total area must have the layer. No fretting of the
base metal is permitted.
Molydag layer on the dovetail pressure faces that is gone Permitted, if it is possible, apply two new molydag layers
before you install the disk.
Sealant that is gone from the blade retainer Permitted.
END OF TASK
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-00
NoC
Page 211
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
