FAN ROTOR BLADES - REPAIRS
1. General
A. This procedure has four tasks: Repair the Fan Blades, Replace and Balance a Fan Rotor Blade Set,
Repair the Fan Case Shroud, and RTV Sealant Repair.
TASK 72-31-02-308-029-G00
2. Repair the Fan Rotor Blades
(Figure 801
, Figure 802)
A. General
(1) You will blend the edges (or surfaces) of the fan rotor blades to do the repair. You can blend
the blades with a high quality file, an abrasive cloth, or an abrasive stone. You can blend with a
slow speed power tool if a large amount of material needs to be removed.
You can do the blend repair on removed blades or while the blades are still on the engine.
B. References
Reference Title
70-11-06 P/B 201 FLUORESCENT PENETRANT INSPECTION - MAINTENANCE
PRACTICES
71-00-00 P/B 501 POWER PLANT - ADJUSTMENT/TEST
72-31-00 P/B 501 FAN AND LOW PRESSURE COMPRESSOR SECTION -
ADJUSTMENT/TEST
72-31-02 P/B 401 FAN ROTOR BLADES - REMOVAL/INSTALLATION
72-31-02 P/B 601 FAN ROTOR BLADES - INSPECTION/CHECK
C. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-12874 Template - Leading Edge, Fan Blade
767-200
Part #: 2C14225G01 Supplier: 06083
D. Location Zones
Zone Area
412 Left Powerplant Nose Cowl
422 Right Powerplant Nose Cowl
E. Procedure
SUBTASK 72-31-02-028-002-G00
CAUTION
MAKE SURE THAT OBJECTS DO NOT FALL THROUGH THE OPEN VALVES
INTO THE ENGINE. DAMAGE TO THE ENGINE CAN OCCUR.
(1) If it is necessary, remove the blade or blades that need repair (PAGEBLOCK 72-31-02/401).
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-02
NoC
Page 801
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
