TASK 72-33-03-402-009-G00
3. Install the Outer OGV's and the Fairings
A. References
Reference Title
71-11-04 P/B 201 FAN COWL PANELS - MAINTENANCE PRACTICES
(OPEN/CLOSE)
71-11-06 P/B 201 CORE COWL PANELS - MAINTENANCE PRACTICES
(OPENING/CLOSING)
72-33-05 P/B 401 ACOUSTICAL LINER SEGMENTS - REMOVAL/INSTALLATION
78-31-00 P/B 201 THRUST REVERSER SYSTEM - MAINTENANCE PRACTICES
B. Consumable Materials
Reference Description Specification
B50082 Primer - Zinc chromate TT-P-1757B
C00057 Primer - Zinc Chromate TT-P-1757B
C50080 Primer - Urethane-compatible,
Corrosion-resistant
BMS10-79 Type I
D50071 [C02-006] Lubricant - Esnalube 382
C. Location Zones
Zone Area
410 Left Powerplant
415 Left Powerplant Fan Reverser - Left
420 Right Powerplant
425 Right Powerplant Fan Reverser - Left
D. Procedure
SUBTASK 72-33-03-422-010-G00
(1) Do the steps that follow to install the OGV:
CAUTION
MAKE SURE THAT YOU INSTALL THE CORRECT OGV PART NUMBER
FOR ITS LOCATION. THERE ARE MANY DIFFERENT OGV PART
NUMBERS FOR DIFFERENT LOCATIONS. AN OGV IN THE INCORRECT
LOCATION CAN HAVE AN EFFECT ON THE ENGINE OPERATION.
DAMAGE TO THE ENGINE CAN OCCUR.
(a) Apply a thin layer of primer to the bolt shank, and to the mating holes on the OGV.
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101, 109, 114, 115
1) Use primer, B50082
ABX 314-999
2) primer, C00057 or urethane-compatible, corrosion-resistant primer, C50080
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101, 109, 114, 115, 314-999
(b) Apply a thin layer of Esnalube 382 Lubricant, D50071 [C02-006] to bolt threads.
(c) Engage the inner end of the OGV with the slots on the inner support panel.
(d) Push the OGV to the inner direction.
(e) Install the spacer adjacent to the outer platform of the OGV.
(f) Install the washers and the 2 bolts (the washers go under the bolt heads).
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-33-03
NoC
Page 205
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
