TASK 72-33-01-408-015-G00
3. Install the 1st-Stage Stator Vane Assembly
A. References
Reference Title
72-31-01 P/B 401 FAN ROTOR SPINNER - REMOVAL/INSTALLATION
72-31-02 P/B 401 FAN ROTOR BLADES - REMOVAL/INSTALLATION
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-6797 Heater - Case, Aft Fan
767-200
Part #: 2C6372G03 Supplier: 06083
Part #: 2C6372G04 Supplier: 06083
STD-1181
Gloves - Heat Protective
C. Consumable Materials
Reference Description Specification
C00057 Primer - Zinc Chromate TT-P-1757B
D50254 Lubricant - Everlube 811 Water Based,
MoS2/Graphite Solid Film Lubricant
MIL-PRF-81329
D. Location Zones
Zone Area
410 Left Powerplant
415 Left Powerplant Fan Reverser - Left
420 Right Powerplant
425 Right Powerplant Fan Reverser - Left
E. Procedure
SUBTASK 72-33-01-428-010-G00
(1) Install the inner shroud on the stator disk.
(a) Make sure the side of the shroud with the part number is in the aft direction.
SUBTASK 72-33-01-428-011-G00
(2) Do the steps that follow to install the 1st-stage stator vane:
(a) Lubricate the threads of the bolts with the Everlube 811 lubricant, D50254.
(b) Apply a layer of primer, C00057 to the shank and the head of the bolts.
(c) Install the trunnion of the 1st-stage stator vane into the empty space of the bushing in the
inner shroud.
(d) Install the nuts and bolts to the outer end of the 1st-stage stator vane and the forward
outer flange of the 2nd-stage outer shroud.
1) The heads of the bolts must be in the aft direction.
2) Tighten the nuts finger tight.
(e) Do a check of the clearance between the forward serration of the 1st-stage seal on the
stator spool and the 1st-stage inner shroud.
