Boeing 767 - Task 72-35-00-008-007-G00 - VSV Actuation Lever Removal; Subtask 72-35-00-018-027-G00; Subtask 72-35-00-938-009-G00; Subtask 72-35-00-038-042-G00

TASK 72-35-00-008-007-G00
7. VSV Actuation Lever Removal
(Figure 802)
A. Consumable Materials
Reference Description Specification
G02061 Marker - Permanent, Felt Tip Pen
B. Location Zones
Zone Area
410 Left Powerplant
420 Right Powerplant
C. Procedure
SUBTASK 72-35-00-018-027-G00
(1) Make sure the task "Preparation for VSV Repairs" has been done.
SUBTASK 72-35-00-938-009-G00
(2) Use a marker, G02061 to put identification numbers on the clevises [7].
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101, 109, 114, 115, 314-999 PRE SB CF6-80A-75-0004
SUBTASK 72-35-00-038-042-G00
CAUTION
DO NOT REMOVE THE JAMNUT LOCKWIRE, LOOSEN THE JAMNUT OR
TURN THE ROD-END BEARING. IF YOU DO NOT OBEY THIS INSTRUCTION,
ENGINE DAMAGE CAN OCCUR.
(3) If the right side lever is removed, disconnect the feedback pushrod [12] but leave the lockwire
attached.
NOTE: The feedback pushrod is on the right side on engines without GE SB 75-004.
(a) Remove the bolt, spacer, washer, nut, and cotter pin that connect the rod end bearing
[13] to the bellcrank.
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101, 109, 114, 115, 314-999 POST SB
CF6-80A-75-0004
SUBTASK 72-35-00-038-083-G00
CAUTION
DO NOT REMOVE THE JAMNUT LOCKWIRE, LOOSEN THE JAMNUT OR
TURN THE ROD-END BEARING. IF YOU DO NOT OBEY THIS INSTRUCTION,
ENGINE DAMAGE CAN OCCUR.
(4) If the left side lever is removed, disconnect the feedback pushrod [12] but leave the lockwire
attached.
NOTE: The feedback pushrod is on the left side on engines with GE SB 75-004.
(a) Remove the bolt, spacer, washer, nut, and cotter pin that connect the rod end bearing
[13] to the bellcrank.
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101, 109, 114, 115, 314-999
SUBTASK 72-35-00-038-010-G00
(5) Disconnect the rod end bearings [7B] from the connecting links [8].
