Boeing 767 - Page 347

A
A
AFT
2
2
1
2
1
1
SEE A
SEE B
SEE C
A
B
C
[12] FEEDBACK
PUSHROD
[13] FEEDBACK ROD END BEARING
(ATTACHES TO BELLCRANK HERE
WITH
BOLT, SPACER, WASHER,
NUT, AND COTTER PIN
ENGINES WITHOUT GE SB 75-004
ENGINES WITH GE SB 75-004
[4] ACTUATION
LEVER GUIDE
[3] ACTUATOR
[12] FEEDBACK PUSHROD
(LEFT)
[13] FEEDBACK ROD END BEARING
(ATTACHES TO BELLCRANK HERE
WITH
BOLT, SPACER, WASHER,
NUT, AND COTTER PIN
[7] CLEVIS
CLEVIS
BOLT
[7A]
PUSHROD
[10] ACTUATION
LEVER
[7] CLEVIS
[2A] WASHER
[2] NUT
[7A] PUSHROD
[7B] ROD END BEARING
[10] ACTUATION LEVER
[1] SPACER
[9] ACTUATION
LEVER MOUNT
CLEVIS BOLT
[8] CONNECTING LINKS
(RIGHT)
BOLT
[6] BOLT, NUT
[4]
ACTUATION
LEVER GUIDE
[3] ACTUATOR
5] BRACKET
[11] LOCKING
BRACKET
[1] SPACER
A-A
0.001 INCH
(0.03 mm)
MINIMUM
[5] BRACKET
[6] BOLT, NUT
BOLT
[7B]
ROD END
BEARING
[2] NUT
[2A] WASHER
[8] CONNECTING LINKS
[9] ACTUATION
LEVER MOUNT
[1] SPACER
26108 S00061423058_V1
VSV Actuation Lever Assembly
Figure 802/72-35-00-990-810-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-35-00
NoC
Page 810
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
