TASK 72-35-00-408-004-G00
4. VSV Lever Arm (IGV thru 5th-Stage) Installation
(Figure 801)
A. Location Zones
Zone Area
410 Left Powerplant
420 Right Powerplant
B. Procedure
SUBTASK 72-35-00-018-026-G00
(1) Make sure the task "Preparation for VSV Repairs" has been done.
SUBTASK 72-35-00-428-005-G00
(2) Install the 5th-Stage lever arm as follows:
(a) Install the lever arm [3] and the locknut [1].
(b) Tighten the locknut to 90-100 pound-inches (10.2-11.3 newton-meters).
SUBTASK 72-35-00-428-006-G00
(3) Install the IGV thru 4th-Stage lever arm as follows:
(a) Install the lever arm [3], sleeve [4] and locknut [1].
1) Align the identification marks.
CAUTION
YOU MUST REPLACE THE LOCKNUT IF THE RUN-ON TORQUE IS LESS
THAN 5 IN-LB (0.6 N.M) OR IF MORE THAN 40 IN-LB (4.5 N.M). IF THE
LOCKNUT RUN-ON TORQUE IS NOT CORRECT, DAMAGE TO THE
ENGINE CAN OCCUR.
(b) Remove the lockwire and tighten the locknut to run-on torque.
1) If the run-on torque is less than 5 pound-inches (0.6 newton-meters) or more than
40 pound-inches (4.5 newton-meters), replace the nut.
(c) On IGV, 1st- and 2nd-stage lever arms; tighten the locknut to 50-60 pound-inches
(5.7-6.8 newton-meters).
(d) On 3rd- and 4th-stage lever arms; tighten the locknut to 85-95 pound-inches (9.6-10.8
newton-meters).
(e) Do a check of the vane assembly to make sure that a small movement is possible.
1) Hold the vane between your thumb and forefinger, and try to move the vane.
2) You must feel a very small movement of the vane.
a) If you do not feel a small movement of the vane, do the steps to install the
lever arm again.
SUBTASK 72-35-00-048-029-G00
(4) If no more work will be done at this time, do the task "Put the Airplane to its Usual Condition
After VSV Repairs".
END OF TASK
