Component Removed Use tool number
Fuel Pump removal tool, SPL-5655
Main Engine Control removal tool, SPL-5655
Starter ring removal tool, SPL-5656
Hydraulic Pump removal tool, SPL-5655
IDG ring removal tool, SPL-5656
SUBTASK 72-61-02-944-011-G00
(2) Do the steps that follow to prepare the removal tool:
(a) Turn the screw in the removal tool all the way counterclockwise to retract the pusher
plate.
(b) Move the outer sleeve back to let the flexible fingers of the inner sleeve extend.
SUBTASK 72-61-02-434-012-G00
(3) Install the removal tool into the empty space (where the oil seal was installed).
(a) Apply pressure on the removal tool until the plastic stop touches the mating ring.
SUBTASK 72-61-02-434-013-G00
(4) Slide the outer sleeve over the inner sleeve.
NOTE: The flexible fingers will close over the mating ring.
SUBTASK 72-61-02-434-014-G00
(5) Use a ratchet wrench with a 1/2 inch socket to tighten the screw in a clockwise direction.
(a) Tighten until you pull the mating ring out of the shaft.
SUBTASK 72-61-02-034-015-G00
(6) Remove the removal tool.
(a) Move the outer sleeve back to release the mating ring.
(b) Discard the packing and the mating ring.
END OF TASK
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-61-02
NoC
Page 403
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
