FAN ROTOR SPINNER - REMOVAL/INSTALLATION
TASK 72-31-01-024-001-G00
1. Remove the Fan Rotor Spinner
A. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-6380 Tool - Fan Spinner Removal
767-200
Part #: 2C6894G04 Supplier: 06083
STD-6378
Protective Mat - Rubber, Manufacturers Association, Grade SC43,
neoprene sponge, 1 inch thick, approximately 3 x 4 feet with warning
streamer attached
B. Location Zones
Zone Area
412 Left Powerplant Nose Cowl
422 Right Powerplant Nose Cowl
C. Procedure
SUBTASK 72-31-01-944-018-G00
CAUTION
MAKE SURE THAT THE EDGES OF THE PROTECTIVE MATS ARE TIGHT
TOGETHER OR SEALED WITH TAPE. THIS WILL PREVENT DAMAGE FROM
TOOLS, PARTS, OR UNWANTED MATERIALS THAT FALL ON THE INLET
COWL SURFACE.
(1) Put protective mats, STD-6378 (3 required) in the inlet cowl so all of the lower half of the cowl
surface is covered.
SUBTASK 72-31-01-864-002-G00
CAUTION
YOU MUST PUT AN IDENTIFICATION MARK ON ALL THE REMOVED PARTS.
DAMAGE TO THE ENGINE CAN OCCUR IF THE PARTS ARE NOT PUT BACK
IN THE CORRECT LOCATION.
CAUTION
USE ONLY APPROVED COMPOUNDS TO MAKE A MARK ON THE ENGINE
PARTS. IF COMPOUNDS THAT ARE NOT APPROVED ARE USED, DAMAGE
CAN OCCUR TO THE ENGINE PARTS.
(2) Put a mark on the spinner (Figure 401).
(a) Find the offset hole in the spinner. It is painted white, and identified with the letter "O".
(b) Find blade No. 1. It is the second blade, counterclockwise from the offset hole.
(c) Put a mark on the spinner and the platform of the first-stage disk to help make sure it will
be aligned correctly when it is installed.
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-01
NoC
Page 401
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
