(a) Mix the initial coating mixture in a ratio of one part Metcoseal AP adhesive, A01044
[C01-030] to one part Metroseal APT thinner, B00674 [C01-031].
(b) Apply one layer of the mixture to the surface of the thrust reverser supports.
(c) Permit the adhesive to air dry for 30 minutes.
(d) Apply one layer of the adhesive that you have not mixed with the thinner.
(e) Permit to air dry for 30 minutes.
SUBTASK 72-33-04-418-033-G00
(5) If no more repairs will be done at this time, do these steps to put the airplane to its usual
condition:
(a) Close the thrust reversers (PAGEBLOCK 78-31-00/201).
(b) Close the fan cowl panels (PAGEBLOCK 71-11-04/201).
END OF TASK
TASK 72-33-04-308-039-G00
6. Chevron Seals on the Fan Frame Repair
(Figure 804)
A. Consumable Materials
Reference Description Specification
A50311 [C01-006] Adhesive - RTV Silicone Elastomer MIL-A-46106 Type I
G00034 Cotton Wiper - Process Cleaning Absorbent
Wiper (Cheesecloth, Gauze)
BMS15-5 Class A
B. Location Zones
Zone Area
410 Left Powerplant
420 Right Powerplant
C. Procedure
SUBTASK 72-33-04-358-041-G00
(1) Do these steps to prepare for the chevron seal repair:
(a) Cut and remove the damaged section of the chevron seal.
(b) From a piece of salvaged chevron seal, cut a replacement piece.
NOTE: The replacement piece can be less than 0.020 inch (on each end) in length than
the original piece.
(c) Use a clean, dry cotton wiper, G00034 to clean all the surfaces of the repair area and the
replacement seal.
SUBTASK 72-33-04-358-042-G00
(2) Do these steps to install the fiberglass cloth and apply RTV Silicone Elastomer adhesive,
A50311 [C01-006]:
(a) Cut two pieces of fiberglass cloth approximately 0.5 inch (12.7 mm) by 1.0 inch (25.4
mm) in dimension to fit on the two sides of the splice area.
1) The fiberglass cloth must not extend more than 0.45-0.55 inch (11.4-14.0 mm) from
the edge of the chevron seal.
2) The fiberglass cloth must not be on the seating area of the chevron seal.
(b) Apply a thin coat of silicone adhesive on the chevron seal at each splice area.
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-33-04
NoC
Page 815
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
