(g) Tighten to 160-210 pound-inches (18.0-23.7 newton meters).
SUBTASK 72-33-03-422-011-G00
(2) Do the steps that follow to install the fairings:
(a) Apply a thin layer of Esnalube 382 Lubricant, D50071 [C02-006] to the threads of the
fairing screws.
(b) Install the fairing on the fan case between the OGV's.
(c) Install the screws that hold the fairing.
(d) Use a soft mallet to lightly hit the two ends of the fairing to make sure it is engaged.
(e) Tighten the screws.
(f) Loosen the screws.
(g) Lightly hit the fairing again to make sure it is engaged.
(h) Tighten the screws again.
(i) If you will install more fairings, work in a clockwise direction (forward to aft).
SUBTASK 72-33-03-412-012-G00
(3) If necessary, install the acoustical liner section (PAGEBLOCK 72-33-05/401) that was removed
to get access to the OGV.
E. Put the Airplane to its Usual Condition
SUBTASK 72-33-03-412-013-G00
WARNING
OBEY THE INSTRUCTIONS IN THE PROCEDURE TO CLOSE THE THRUST
REVERSERS. IF YOU DO NOT OBEY THE INSTRUCTIONS, INJURIES TO
PERSONS AND DAMAGE TO EQUIPMENT CAN OCCUR.
(1) Close the thrust reversers (PAGEBLOCK 78-31-00/201).
SUBTASK 72-33-03-412-014-G00
(2) Close the core cowl panels (PAGEBLOCK 71-11-06/201).
SUBTASK 72-33-03-442-015-G00
(3) Do the activation procedure for the thrust reverser (PAGEBLOCK 78-31-00/201).
SUBTASK 72-33-03-412-016-G00
(4) Close the fan cowl panel (PAGEBLOCK 71-11-04/201).
END OF TASK
TASK 72-33-03-202-018-G00
4. Examine the OGV's and the Fairings
(Figure 201)
A. References
Reference Title
70-11-06 P/B 201 FLUORESCENT PENETRANT INSPECTION - MAINTENANCE
PRACTICES
72-33-05 P/B 601 ACOUSTICAL LINER SEGMENTS - INSPECTION/CHECK
B. Consumable Materials
Reference Description Specification
A50119 Adhesive - Silicone Rubber - RTV 103 (Black) MIL-A-46106
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-33-03
NoC
Page 206
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
To Next Page
