Boeing 767 - Pageblock 72-33-04;801 - FAN FRAME - REPAIRS; Task 72-33-04-308-001-G00 - Abradable Shroud Repair

FAN FRAME - REPAIRS
1. General
A. This procedure has these five tasks:
• Abradable Shroud Repair
• Stowage of the Inlet Cowl Nuts that are Not Used
• Cracked Casing Rib Repair
• Thrust Reverser Support Wear Coating Repair
• Chevron Seals on the Fan Frame Repair
TASK 72-33-04-308-001-G00
2. Abradable Shroud Repair
(Figure 801)
A. General
(1) This task gives instructions on how to repair the abradable shroud. There are also instructions
on how to repair the fiberglass fiber and the honeycomb material (these two materials are
below the abradable shroud).
B. References
Reference Title
72-31-01 P/B 401 FAN ROTOR SPINNER - REMOVAL/INSTALLATION
72-31-02 P/B 401 FAN ROTOR BLADES - REMOVAL/INSTALLATION
C. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-6797 Heater - Case, Aft Fan
767-200
Part #: 2C6372G03 Supplier: 06083
Part #: 2C6372G04 Supplier: 06083
STD-6378
Protective Mat - Rubber, Manufacturers Association, Grade SC43,
neoprene sponge, 1 inch thick, approximately 3 x 4 feet with warning
streamer attached
STD-6635
Gloves - polyethylene
STD-6638
Air Source - Compressed, Clean, Filtered, and Dry, 0 - 100 psi
D. Consumable Materials
Reference Description Specification
A00949 [C01-060] Adhesive - Abradable Seal Material GE P6TF1 Class A
A01059 [C01-011] Paste - Adhesive, Two Part (Hysol EA 934NA) A50TF94 Class B
B00148 Solvent - Methyl Ethyl Ketone (MEK) ASTM D740
G00031 Fabric - Glass, Finished, For Resin Laminates
(Type VIIIA)
SAE-AMS-C-9084 Type
VIIIA (MIL-C-9084
canceled)
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-33-04
NoC
Page 801
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
