Boeing 767 - Subtask 72-53-02-014-017-G00; Subtask 72-53-02-014-018-G00

ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101, 109, 114, 115, 314-999 POST SB
CF6-80A-72-A675
SUBTASK 72-53-02-014-017-G00
(8) Remove nut [7] and bolt [6] that attach loop clamp [8] and C-sump oil supply line [9] to bracket
[3] (Figure 401 or Figure 402 or Figure 403).
SUBTASK 72-53-02-014-018-G00
(9) Remove the bracket [3], flame arrestor [2], insulation blanket [1], carbon seal housing [13], oil
slinger [11], and center vent tube [10] (Figure 401 or Figure 402 or Figure 403).
WARNING
DO NOT TOUCH INSULATION BLANKETS WITHOUT GLOVES OR
SPECIAL EQUIPMENT. THE INSULATION BLANKETS CAN CONTAIN
CERAMIC FIBERS THAT CAN CAUSE DAMAGE TO YOUR SKIN, EYES,
AND LUNGS. IF YOU DO NOT USE SKIN, EYE, AND LUNG
PROTECTION, YOU CAN CAUSE INJURIES TO PERSONNEL.
(a) Remove the eight nuts [4] that attach the bracket [3], flame arrestor [2], insulation blanket
[1], and carbon seal housing [13] to the aft sump housing.
(b) Remove the bracket [3], flame arrestor [2], insulation blanket [1], and carbon seal housing
[13].
(c) Remove the seven nuts [12] that attach the oil slinger [11] and center vent tube [10] to the
No. 6 bearing spanner nut.
(d) Remove the oil slinger [11] and center vent tube [10].
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101, 109, 114, 115, 314-999
END OF TASK
