SEE
A
FWD
A
[8]
CLAMP
[3] AFT NO.
6
BEARING
COVER
[4]
PACKING
[2]
INSULATION
BLANKET
[1] NUT
[11]
BRACKET
[9] NUT
[1] NUT
[12]
OIL
SUPPLY
LINE
[10] BOLT
TURBINE
REAR
FRAME
[5] OIL
SLINGER
[15]
NUT
[6]
INTEGRAL
SEAL
TUBING
RING
[7]
FLAME
ARRESTER
[13]
NO.
6
BEARING
PLUG
[14]
PACKING
DUCT
ASSEMBLY
SPANNER
NUT
1184088-00-A
L80765 S00061423181_V1
C-Sump Vent Installation
Figure 402/72-53-02-990-803-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-53-02
NoC
Page 406
D633T1B7 Dec 22/2016
