B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-5653 Tool - Install, Accessory Gearbox (AGB) Mating Ring
767-200
Part #: 2C14137G02 Supplier: 06083
Opt Part #: 2C14137G01 Supplier: 06083
C. Consumable Materials
Reference Description Specification
D00068 Oil - Aircraft Turbine Engine, Synthetic Base MIL-PRF-23699 Class
STD (Standard)
D50223 [C02-008] Jelly - Petroleum VV-P-236
D. Location Zones
Zone Area
410 Left Powerplant
415 Left Powerplant Fan Reverser - Left
420 Right Powerplant
425 Right Powerplant Fan Reverser - Left
E. Procedure
SUBTASK 72-61-02-434-017-G00
(1) Do the steps that follow to install the mating ring:
(a) Apply a light layer of oil, D00068 to the new packing.
(b) Install the packing on the new mating ring.
(c) Use the installation tool from the list that follows to install the mating ring:
Component Removed Use tool number
Fuel Pump installation tool, SPL-5653
Main Engine Control installation tool, SPL-5653
Starter
Hydraulic Pump installation tool, SPL-5653
IDG
(d) Use the installation tool to hold the outer diameter of the mating ring.
(e) Insert the installation tool into the gearshaft until it touches the inner race of the bearing.
CAUTION
MAKE SURE THAT THE TANGS ON THE MATING RING ENGAGE WITH
THE SLOTS IN THE INNER BEARING RACE. IF THEY DO NOT, DAMAGE
TO THE EQUIPMENT CAN OCCUR.
(f) Turn the installation tool until the tangs of the mating ring engage the slots in the bearing
inner race.
SUBTASK 72-61-02-424-018-G00
(2) Do the steps that follow to install the oil seal:
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-61-02
NoC
Page 406
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
