FAN ROTOR BLADES - REMOVAL/INSTALLATION
1. General
A. This procedure contains:
(1) Fan Rotor Removal
(2) Fan Rotor Installation
TASK 72-31-02-004-034-G00
2. Remove the Fan Rotor Blades
A. General
(1) This task gives instructions on how to remove the fan rotor blades. You can use this procedure
to remove one blade (or more) or a set of fan rotor blades.
B. Tool Information
(1) Tool, Spacer - Removal/Install, 2C8073G01, General Electric Company, Cincinnati, Ohio
45215
C. References
Reference Title
72-31-01 P/B 401 FAN ROTOR SPINNER - REMOVAL/INSTALLATION
D. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-5662 Extractor - Stg 1 Fan Blade Retainer Spacer
767-200
Part #: MSE-54 Supplier: 06083
SPL-6387 Tool - Preload, Fan Blade
767-200
Part #: 2C8073G05 Supplier: 06083
STD-6378
Protective Mat - Rubber, Manufacturers Association, Grade SC43,
neoprene sponge, 1 inch thick, approximately 3 x 4 feet with warning
streamer attached
STD-7049
Marker
E. Location Zones
Zone Area
412 Left Powerplant Nose Cowl
422 Right Powerplant Nose Cowl
F. Procedure
SUBTASK 72-31-02-944-002-G00
(1) Put a protective mat, STD-6378 in the bottom half of the inlet cowl.
SUBTASK 72-31-02-014-003-G00
(2) Remove the fan rotor spinner (PAGEBLOCK 72-31-01/401).
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-02
NoC
Page 401
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
