FAN ROTOR DISK - REMOVAL/INSTALLATION
1. General
A. This procedure gives the steps to remove and install the fan rotor (stage 1) disk. The parts that will
be used again need to be matchmarked or numbered to make sure the reassembly is correct.
TASK 72-31-00-024-001-G00
2. Remove the Fan Rotor Disk
A. References
Reference Title
71-11-01 P/B 401 INLET COWL - REMOVAL/INSTALLATION
72-31-00 P/B 201 FAN (AND LOW PRESSURE COMPRESSOR) SECTION -
MAINTENANCE PRACTICES
72-31-01 P/B 401 FAN ROTOR SPINNER - REMOVAL/INSTALLATION
72-31-02 P/B 401 FAN ROTOR BLADES - REMOVAL/INSTALLATION
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-6714 Protector - Fan Disk Bore, Stage 1
767-200
Part #: 2C6075G03 Supplier: 06083
SPL-6736 Tool Set - Removal/Installation, Stage 1Fan Disk Nuts
767-200
Part #: 2C14773G02 Supplier: 06083
SPL-6737 Adapter Set - Install/Remove, Stage 1 Fan Disk Nuts
767-200
Part #: 2C14738G01 Supplier: 06083
SPL-6742 Adapter - Anti-Torque Stop Arm
767-200
Part #: 2C14685G01 Supplier: 06083
SPL-6743 Remove/Install Fixture - Bolts, Forward Fan Shaft
767-200
Part #: 2C6122G02 Supplier: 06083
SPL-6797 Heater - Case, Aft Fan
767-200
Part #: 2C6372G03 Supplier: 06083
Part #: 2C6372G04 Supplier: 06083
SPL-6914 Lift Fixture - Fan Rotor Subassembly
767-200
Part #: 2C6856G03 Supplier: 06083
SPL-13244 Adapter - Fan Rotor disk
767-200
Part #: 2C6827G05 Supplier: 06083
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-00
NoC
Page 401
D633T1B7 Apr 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
