TASK 72-35-00-008-043-G00
10. Slot Loaded Bearing Ball Removal
A. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-6993 Tool Set - VSV Lever Bushing Install/Remove
B. Location Zones
Zone Area
410 Left Powerplant
420 Right Powerplant
C. Procedure
SUBTASK 72-35-00-848-044-G00
(1) Make sure that the task "Preparation for VSV Repairs" has been done.
SUBTASK 72-35-00-848-045-G00
(2) Do the preparation steps that follow (Figure 802):
(a) Disconnect the rod end bearing [7B] from the connecting link [8].
CAUTION
DO NOT REMOVE THE JAMNUT LOCKWIRE, LOOSEN THE JAMNUT OR
TURN THE ROD-END BEARING. IF YOU DO NOT OBEY THIS
INSTRUCTION, ENGINE DAMAGE CAN OCCUR.
(b) If you will remove the feedback rod end bearing, disconnect the feedback pushrod [12],
leave the lockwire attached.
1) Remove the bolt, spacer, washer, and the nut that connects the rod end bearing [7]
to the bellcrank.
(c) If it is necessary, remove the clevis bolts and nuts to disconnect the pushrod [7A] , the
rod end bearing [7B] and the clevis [7] from the actuation lever [10].
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101, 109, 114, 115, 314-999 PRE SB CF6-80A-72-0498
(d) Remove the inserts from the slot loaded bearing (Figure 808), use tool set, SPL-6993.
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101, 109, 114, 115, 314-999
(e) Align the bearing ball with the loading slots.
(f) Use finger pressure from the opposite side and remove the bearing ball (Figure 807).
END OF TASK
