A
A
[7]
WASHER
PLAIN 0.250
INCH
(6.35
mm)
NOMINAL
SIZE
[5]
SCREW
0.250-20
UNC
x
1.75
INCHES
(44.5
mm)
LARGE
THREADED
WITHIN
0.18 INCH
(4.6
mm)
OF
HEAD-HEX
SOCKET
HEAD TYPE
[3]
BLOCK
-
RELIEVED
[4]
SCREW
(SPECIAL
HEX
SOCKET
HEAD)
[6]
HEXNUT
0.250-20
UNC
THREAD
[5]
SCREW
0.250-20
UNC
x
1.75
INCHES
(44.5
mm)
LARGE-.THREADED
WITHIN
0.18 INCH
(4.6
mm)OF
HEAD-HEX
SOCKET
HEAD TYPE
[2]
BLOCK
-
PILOTED
[1]
BLOCK
-
THREADED
CF6-E3627-0-A2A
INSTALLATION
OF
INSERTS
REMOVAL
OF
REMAINING
INSERT
REMOVAL
OF
ONE
OR
BOTH
INSERTS
B-BA-A
B
B
C49793 S00061423069_V1
Removal/Installation of Inserts from the VSV Actuation Lever Slot Loaded Bearing with Tool 2C7798
Figure 808/72-35-00-990-816-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-35-00
NoC
Page 822
D633T1B7 Dec 22/2016
