Boeing 767 - Task 72-31-00-424-003-G00 - Install the Fan Rotor Disk

TASK 72-31-00-424-003-G00
3. Install the Fan Rotor Disk
A. References
Reference Title
71-00-00 P/B 501 POWER PLANT - ADJUSTMENT/TEST
71-11-01 P/B 401 INLET COWL - REMOVAL/INSTALLATION
72-31-00 P/B 201 FAN (AND LOW PRESSURE COMPRESSOR) SECTION -
MAINTENANCE PRACTICES
72-31-01 P/B 401 FAN ROTOR SPINNER - REMOVAL/INSTALLATION
72-31-02 P/B 401 FAN ROTOR BLADES - REMOVAL/INSTALLATION
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-6736 Tool Set - Removal/Installation, Stage 1Fan Disk Nuts
767-200
Part #: 2C14773G02 Supplier: 06083
SPL-6737 Adapter Set - Install/Remove, Stage 1 Fan Disk Nuts
767-200
Part #: 2C14738G01 Supplier: 06083
SPL-6738 Guide Pin - Fan Rotor Installation
767-200
Part #: 2C6348P02 Supplier: 06083
SPL-6742 Adapter - Anti-Torque Stop Arm
767-200
Part #: 2C14685G01 Supplier: 06083
SPL-6797 Heater - Case, Aft Fan
767-200
Part #: 2C6372G03 Supplier: 06083
Part #: 2C6372G04 Supplier: 06083
SPL-6914 Lift Fixture - Fan Rotor Subassembly
767-200
Part #: 2C6856G03 Supplier: 06083
SPL-13244 Adapter - Fan Rotor disk
767-200
Part #: 2C6827G05 Supplier: 06083
SPL-13245 Support Stand - Fan Rotor
767-200
Part #: 2C6830G02 Supplier: 06083
C. Consumable Materials
Reference Description Specification
A01050 [C01-007] Adhesive - Silicone Elastomer - RTV 106
A50213 [C01-057
(Supersedes
C01-080)]
Adhesive - Liquid GE A15B70A3,
A-A-3097 Type 1 Class
2
