(a) Lubricate the new packing with oil, D00068.
(b) Install the new packing in the adapter grooves.
CAUTION
DO NOT USE FORCE ON THE ADAPTER. DO NOT USE BOLTS TO
INSTALL THE ADAPTER. MAKE SURE THE ROLLER BEARING
ENGAGES WITH THE OUTER RACE. MAKE SURE THE GEAR TEETH
ARE ENGAGED CORRECTLY. DAMAGE TO EQUIPMENT CAN RESULT.
(c) Lubricate the roller bearing with grease or oil.
(d) Carefully push the roller bearing into the race of the adapter.
(e) Align the stud holes in the adapter with the holes in the gearbox.
(f) Carefully insert the adapter into the gearbox.
(g) Install the washers, bolts and the shoulder studs as necessary.
1) Use the across and across procedure to tighten the bolts (or shoulder studs) to
55-70 pound-inches (6.2-7.9 newton meters).
(h) Install the brackets and tube clamps as necessary.
SUBTASK 72-61-03-554-025-G00
(4) Install the applicable accessory part on the gearbox.
Adapter No. Accessory Procedure
3 Hydraulic Pump PAGEBLOCK 29-11-05/401 Config 4
4 IDG PAGEBLOCK 24-11-01/401 Config 3
5 Lube and Scavenge Pump PAGEBLOCK 79-21-03/401
6 Starter PAGEBLOCK 80-11-01/401
7 MEC PAGEBLOCK 73-21-01/401
8 Fuel Pump PAGEBLOCK 73-11-01/401
9 EEC Generator PAGEBLOCK 73-21-08/401
G. Put the Airplane to its Usual Condition
SUBTASK 72-61-03-414-026-G00
WARNING
OBEY THE INSTRUCTIONS IN THE PROCEDURE TO CLOSE THE THRUST
REVERSERS. IF YOU DO NOT OBEY THE INSTRUCTIONS, INJURIES TO
PERSONS AND DAMAGE TO EQUIPMENT CAN OCCUR.
(1) Close the thrust reversers (PAGEBLOCK 78-31-00/201).
SUBTASK 72-61-03-414-027-G00
(2) Close the core cowl panels (PAGEBLOCK 71-11-06/201).
SUBTASK 72-61-03-444-028-G00
(3) Do the activation procedure for the thrust reverser (PAGEBLOCK 78-31-00/201).
SUBTASK 72-61-03-414-029-G00
(4) Close the fan cowl panel (PAGEBLOCK 71-11-04/201).
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-61-03
NoC
Page 409
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
