FAN OUTER OUTLET GUIDE VANES (OGV'S) AND FAIRINGS - MAINTENANCE PRACTICES
1. General
A. This procedure gives instructions on how to remove, install, and examine the fan outer outlet guide
vanes and the fairings. Some repair procedures are included in the inspection.
B. In this procedure the fan outer outlet guide vanes are referred to as the OGV's.
TASK 72-33-03-002-001-G00
2. Remove the OGV's and the Fairings
(Figure 201)
A. References
Reference Title
71-11-04 P/B 201 FAN COWL PANELS - MAINTENANCE PRACTICES
(OPEN/CLOSE)
71-11-06 P/B 201 CORE COWL PANELS - MAINTENANCE PRACTICES
(OPENING/CLOSING)
72-33-05 P/B 401 ACOUSTICAL LINER SEGMENTS - REMOVAL/INSTALLATION
78-31-00 P/B 201 THRUST REVERSER SYSTEM - MAINTENANCE PRACTICES
B. Location Zones
Zone Area
410 Left Powerplant
415 Left Powerplant Fan Reverser - Left
420 Right Powerplant
425 Right Powerplant Fan Reverser - Left
C. Prepare for Removal
SUBTASK 72-33-03-012-002-G00
(1) Open the fan cowl panels (PAGEBLOCK 71-11-04/201).
SUBTASK 72-33-03-042-003-G00
WARNING
DO THE THRUST REVERSER DEACTIVATION PROCEDURE TO PREVENT
THE OPERATION OF THE THRUST REVERSER. THE ACCIDENTAL
OPERATION OF THE THRUST REVERSER CAN CAUSE INJURIES TO
PERSONS OR DAMAGE TO EQUIPMENT.
(2) Do this procedure: Thrust Reverser Deactivation for Ground Maintenance
(PAGEBLOCK 78-31-00/201).
SUBTASK 72-33-03-012-004-G00
(3) Open the core cowl panels (PAGEBLOCK 71-11-06/201).
D. Remove the outer OGV's and the fairings
SUBTASK 72-33-03-032-005-G00
(1) Remove the screws that hold the fairings to the aft fan case.
SUBTASK 72-33-03-022-006-G00
(2) Remove the fairing.
SUBTASK 72-33-03-032-007-G00
(3) Remove the bolts that hold the OGV to the aft fan case.
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-33-03
NoC
Page 201
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
