HIGH PRESSURE COMPRESSOR - INSPECTION/CHECK
1. General
A. This procedure contains two tasks:
(1) The first task examines the external areas of the high pressure compressor (HPC). This
includes the actuator system for the variable stator vanes (VSVs).
(2) The second task examines the HPC for VSV off-schedule operation.
B. The inspection of the high pressure compressor only includes an inspection of the external areas.
For an inspection of the internal areas of the HPC, refer to 72-00-00/601.
TASK 72-35-00-206-018-G00
2. High Pressure Compressor Inspection
A. References
Reference Title
70-11-06 P/B 201 FLUORESCENT PENETRANT INSPECTION - MAINTENANCE
PRACTICES
71-11-04 P/B 201 FAN COWL PANELS - MAINTENANCE PRACTICES
(OPEN/CLOSE)
71-11-06 P/B 201 CORE COWL PANELS - MAINTENANCE PRACTICES
(OPENING/CLOSING)
72-35-00 P/B 801 HIGH PRESSURE COMPRESSOR - REPAIRS
75-31-03 P/B 501 VARIABLE STATOR VANE (VSV) FEEDBACK CABLE -
ADJUSTMENT/TEST
78-31-00 P/B 201 THRUST REVERSER SYSTEM - MAINTENANCE PRACTICES
B. Consumable Materials
Reference Description Specification
A01050 [C01-007] Adhesive - Silicone Elastomer - RTV 106
D50194 [C02-004] Lubricant - Sprayable Air Drying
C. Location Zones
Zone Area
410 Left Powerplant
420 Right Powerplant
D. Prepare for the Inspection
SUBTASK 72-35-00-046-045-G00
WARNING
DO THE THRUST REVERSER DEACTIVATION PROCEDURE TO PREVENT
THE OPERATION OF THE THRUST REVERSER. THE ACCIDENTAL
OPERATION OF THE THRUST REVERSER CAN CAUSE INJURIES TO
PERSONS OR DAMAGE TO EQUIPMENT.
(1) Do this procedure: Thrust Reverser Deactivation for Ground Maintenance
(PAGEBLOCK 78-31-00/201).
SUBTASK 72-35-00-016-019-G00
(2) Open the fan cowl panels (PAGEBLOCK 71-11-04/201).
SUBTASK 72-35-00-416-044-G00
(3) Open the core cowl panels (PAGEBLOCK 71-11-06/201).
