Boeing 767 - Task 72-35-00-408-046-G00 - Slot Loaded Bearing Ball Installation; Subtask 72-35-00-848-101-G00; Subtask 72-35-00-118-048-G00; Subtask 72-35-00-348-049-G00

TASK 72-35-00-408-046-G00
11. Slot Loaded Bearing Ball Installation
A. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-6993 Tool Set - VSV Lever Bushing Install/Remove
B. Consumable Materials
Reference Description Specification
B00090 Solvent - Inhibited Trichloroethane 1,1,1 MIL-T-81533
B50046 Solvent - Methyl Ethyl Ketone, Technical
Grade
ASTM D740
(Supersedes TT-M-261)
D50194 [C02-004] Lubricant - Sprayable Air Drying
C. Location Zones
Zone Area
410 Left Powerplant
420 Right Powerplant
D. Procedure
SUBTASK 72-35-00-848-101-G00
(1) Make sure the task "Preparation for VSV Repairs" has been done.
SUBTASK 72-35-00-118-048-G00
WARNING
DO NOT GET SOLVENTS IN YOUR MOUTH OR EYES, OR ON YOUR SKIN.
DO NOT BREATHE THE FUMES FROM SOLVENTS. PUT ON A RESPIRATOR,
PROTECTIVE SPLASH GOGGLES, AND GLOVES WHEN YOU USE
SOLVENTS. KEEP THE SOLVENTS AWAY FROM SPARKS, FLAME, AND
HEAT. SOLVENTS ARE POISONOUS AND FLAMMABLE. SOLVENTS CAN
CAUSE INJURIES TO PERSONNEL, AND DAMAGE TO EQUIPMENT.
(2) Clean the outer race of the slot loaded bearing (Figure 807) with solvent, B00090 or technical
grade methyl ethyl ketone, B50046.
SUBTASK 72-35-00-348-049-G00
(3) Apply sprayable air drying lubricant, D50194 [C02-004] lubricant to the outer race of the slot
loaded bearing.
SUBTASK 72-35-00-438-050-G00
(4) Put the bearing ball through the loading slot in the outer bearing race.
(a) Turn it to the correct position.
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101, 109, 114, 115, 314-999 PRE SB CF6-80A-72-0498
SUBTASK 72-35-00-428-051-G00
(5) Install the inserts into the slot loaded bearing (Figure 808), use tool set, SPL-6993.
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101, 109, 114, 115, 314-999
