FAN ROTOR SPINNER - INSPECTION/CHECK
1. General
A. You will examine only the external areas of the fan rotor spinner.
TASK 72-31-01-216-001-G00
2. Fan Rotor Spinner Inspection
A. References
Reference Title
70-11-06 P/B 201 FLUORESCENT PENETRANT INSPECTION - MAINTENANCE
PRACTICES
71-00-02 P/B 401 POWER PLANT - REMOVAL/INSTALLATION
72-31-00 P/B 201 FAN (AND LOW PRESSURE COMPRESSOR) SECTION -
MAINTENANCE PRACTICES
72-31-00 P/B 401 FAN ROTOR DISK - REMOVAL/INSTALLATION
B. Location Zones
Zone Area
412 Left Powerplant Nose Cowl
422 Right Powerplant Nose Cowl
C. Procedure
SUBTASK 72-31-01-216-002-G00
(1) Examine the external surfaces of the spinner for the conditions that follow:
NOTE: If you are not sure about the cracks, use the procedure for the spot fluorescent
penetrant inspection (PAGEBLOCK 70-11-06/201).
CONDITION MAXIMUM SERVICEABLE LIMITS
Cracks Not permitted. Replace the spinner (PAGEBLOCK 72-31-00/401) if it
is necessary.
Nicks and scratches Permitted, if they are less than 0.030 inch (0.76 mm) in depth and
less than 1.0 inch (25.4 mm) apart. Replace the spinner if it is
necessary (PAGEBLOCK 72-31-00/401).
Dents Permitted, if they are 0.125 inch (3.18 mm) in depth or less. Replace
the spinner if it is necessary (PAGEBLOCK 72-31-00/401).
Erosion (anodize coating that is gone) Permitted.
Broken or cracked rabbet tabs Not permitted. Replace the spinner if it is necessary
(PAGEBLOCK 72-31-00/401).
Fuel-oil leakage Not permitted. Remove the engine (PAGEBLOCK 71-00-02/401)
and do the shop level HPC rotor bore inspection for fuel-in-oil
contamination.
Oil leakage Not permitted. Remove and replace the preformed packings on the
No. 1 bearing manifold (PAGEBLOCK 72-31-00/201).
END OF TASK
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-01
NoC
Page 601
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
