SEE
A
A
FWD
1092759-00-A
STAGE 1
FAN BLADE
SPINNER
STAGE 1
FAN DISK
THE THREE GREEN
DOTS ARE ON THIS
SURFACE
SPINNER
SEAL RING
820049 S00061422882_V1
Seal Ring Installation
Figure 402/72-31-01-990-802-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-01
NoC
Page 406
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
