SUBTASK 72-35-00-018-033-G00
(2) Open the fan cowl panels (PAGEBLOCK 71-11-04/201).
SUBTASK 72-35-00-418-034-G00
(3) Open the core cowl panels (PAGEBLOCK 71-11-06/201).
SUBTASK 72-35-00-018-035-G00
WARNING
OBEY THE INSTRUCTIONS IN THE PROCEDURE TO OPEN THE THRUST
REVERSERS. IF YOU DO NOT OBEY THE INSTRUCTIONS, INJURIES TO
PERSONS AND DAMAGE TO EQUIPMENT CAN OCCUR.
(4) Open the thrust reversers (PAGEBLOCK 78-31-00/201).
END OF TASK
TASK 72-35-00-008-001-G00
3. VSV Lever Arm (IGV thru 5th-Stage) Removal
(Figure 801
, Figure 802)
A. Location Zones
Zone Area
410 Left Powerplant
420 Right Powerplant
B. Procedure
SUBTASK 72-35-00-018-025-G00
(1) Make sure the task "Preparation for VSV Repairs" has been done.
SUBTASK 72-35-00-028-002-G00
(2) Remove the 5th-Stage VSV lever arm as follows:
(a) Remove the locknut [1] and the lever arm [3].
(b) Replace the pin sleeve [4] in the actuation ring if it is necessary.
SUBTASK 72-35-00-028-003-G00
(3) Remove the IGV thru 4th-Stage VSV lever arm as follows:
(a) Use a felt tip pen to put identification marks on the spacer [11], the tang of the vane [7],
and the outer diameter of the case.
(b) Slowly loosen the locknut [1] until half the threads are not engaged with the vane stud.
CAUTION
YOU MUST SAFETY THE VANE VERY CAREFULLY. IF THE VANE FALLS
INTO THE CASE, AN ENGINE REMOVAL IS REQUIRED TO REMOVE
THE VANE. ENGINE DAMAGE CAN OCCUR.
(c) Carefully lift the lever arm [3] and use lockwire to attach the vane [7] below the lever arm.
1) Make the lockwire tight.
(d) Remove the nut, sleeve [2], and the lever arm [3].
(e) Replace the pin sleeve [4] in the actuation ring if it is necessary.
END OF TASK
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-35-00
NoC
Page 802
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
