E. Location Zones
Zone Area
412 Left Powerplant Nose Cowl
422 Right Powerplant Nose Cowl
F. Prepare to Repair the Abradable Shroud
SUBTASK 72-33-04-948-002-G00
(1) Put the protective mats, STD-6378 (3 required) in the inlet cowl, around the area where you
will do the repair.
SUBTASK 72-33-04-018-003-G00
(2) Remove the fan rotor spinner (PAGEBLOCK 72-31-01/401).
SUBTASK 72-33-04-018-004-G00
(3) Remove the fan rotor blades (PAGEBLOCK 72-31-02/401).
NOTE: Remove only the blades necessary for access to the repair area.
SUBTASK 72-33-04-348-005-G00
(4) Use a hand scraper or a grinder to remove all the loose abradable shroud from the damaged
area.
CAUTION
BE CAREFUL NOT TO CUT THE PLASTIC FACE SHEET THAT IS BELOW
THE ABRADABLE SHROUD MATERIAL. YOU CAN CAUSE DAMAGE TO
THE PLASTIC FACE SHEET.
(a) Remove the abradable shroud to the depth of the plastic face sheet (directly below the
abradable shroud material).
1) Make straight edges (or undercut the edges) on the repair area.
2) Remove the remaining damaged material.
SUBTASK 72-33-04-348-006-G00
(5) Lightly sand the plastic face sheet with 120-grit sandpaper.
(a) Do not cause damage to the fiberglass fibers in the plastic face sheet.
SUBTASK 72-33-04-948-007-G00
(6) Use filtered compressed air to remove the loose particles.
SUBTASK 72-33-04-118-008-G00
WARNING
DO NOT GET CLEANING SOLUTIONS IN YOUR MOUTH, EYES, OR ON
YOUR SKIN. DO NOT BREATHE THE FUMES. PUT ON A PROTECTIVE
SPLASH GOGGLE AND GLOVES WHEN YOU CLEAN. KEEP CLEANING
SOLUTIONS AWAY FROM SPARKS, FLAMES, AND HEAT. CLEANING
SOLUTIONS ARE POISONOUS AND FLAMMABLE, AND CAN CAUSE INJURY
TO PERSONS.
(7) Clean the repair area with solvent, B00148.
G. Replace the Honeycomb and the Fiberglass (if it is necessary)
NOTE: If these materials have a damage area that is more than 35 square inches (226 square cm),
you must do the repair.
SUBTASK 72-33-04-948-009-G00
(1) Prepare the materials as follows:
(a) Use a hand scraper or a grinder to remove all the loose material from the damaged area.
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-33-04
NoC
Page 802
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
