SUBTASK 72-31-01-034-003-G00
CAUTION
MAKE SURE THE SPINNER DOES NOT FALL WHEN IT IS RELEASED FROM
THE DISK.
(3) Loosen and remove the bolts and washers that attach the spinner to the first-stage disk
(Figure 401).
NOTE: Do not loosen the balance weight screws in the spinner.
SUBTASK 72-31-01-024-004-G00
(4) Use the fan spinner removal tool, SPL-6380 to remove the spinner.
SUBTASK 72-31-01-034-005-G00
(5) Remove the seal ring from the forward flange of the first-stage disk (Figure 401).
END OF TASK
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-01
NoC
Page 402
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
