SUBTASK 72-31-02-934-031-G00
WARNING
WEAR HEAVY GLOVES WHEN YOU MOVE OR TOUCH THE FAN BLADES.
THIS WILL PREVENT INJURY TO YOUR HANDS.
CAUTION
YOU MUST PUT AN IDENTIFICATION MARK ON ALL THE REMOVED PARTS.
DAMAGE TO THE ENGINE CAN OCCUR IF THE PARTS ARE NOT PUT BACK
IN THE CORRECT LOCATION.
(3) Use the marker, STD-7049 to put position identification numbers on the fan rotor blades,
retainers, spacers and the disk (Figure 401).
SUBTASK 72-31-02-024-005-G00
(4) Do the steps that follow to remove the fan rotor blade [6]:
(a) Use preload tool, SPL-6387.
(b) Remove the bolt [1] from the No. 1 dovetail slot on the disk.
(c) If it is necessary, remove the balance weights [2].
(d) Use the extractor tool, SPL-5662 to remove the key [5].
(e) Remove the tools.
(f) Hold the fan rotor blade to the radially outer direction, and remove the spacer [4] and the
retainer [3].
(g) Move the fan rotor blade to the radially inner direction to disengage the midspan shroud.
NOTE: If you remove only one blade, first remove the retainer, spacer, and the key from
the adjacent blades. This will give more space to disengage the midspan shroud.
(h) Remove the fan rotor blade from the disk.
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101, 109, 114, 115, 314-999 POST SB
CF6-80A-72-0650
(i) Remove the shim from the fan blade.
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101, 109, 114, 115, 314-999
SUBTASK 72-31-02-554-006-G00
(5) Put the fan rotor blade in the storage container.
SUBTASK 72-31-02-024-007-G00
(6) If you have to remove more fan rotor blades, do again the steps to remove the fan rotor blade.
END OF TASK
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-02
NoC
Page 402
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
